Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine

Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine

Large Image :  Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine

Product Details:
Place of Origin: China
Brand Name: M&J
Certification: CE,ISO9001,CQC,CIQ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $5,800.00 - $8,800.00/sets
Packaging Details: valve bag cement bagging machine, cement bag packing machine PLYWOOD CASE
Supply Ability: 80 Set/Sets per Month
Contact Now

Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine

Description
Warranty: 1 Year Type: Other, Valve Bag Packing Machine
Applicable Industries: Manufacturing Plant Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Warranty Of Core Components: 1 Year Core Components: PLC
Condition: New Application: Chemical, Food, Machinery & Hardware, Medical
Packaging Type: Bags, Stand-up Pouch Packaging Material: Plastic, Paper
Automatic Grade: Semi-automatic Driven Type: Electric
Voltage: 110-415v( Customized) Power: 2kw
Weight: 500 KG Dimension(L*W*H): 1000x790x1800mm
Key Selling Points: Easy To Operate Usage: Outer
Quantitative Range: 5-50kg Marketing Type: New Product 2020
Port: Shanghai Valve Bag Cement Bagging Machine, Cement Bag Packing Machine, Cement Packaging Machinery

Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 0
PRODUCTS DESCRIPTION
Model
LCS
LCS-Y
LCS-Y2
Weighing Range
1-5, 5-10, 10-25, 25-50 Kg/bag, customized needs
Precisions
±0.2%FS
Packing Capacity
150-200bag/hour
250-300bag/hour
480-600bag/hour
Power supply
220V/380V, 50HZ, 1P/3P ( Customized)
Power (KW)
3.2
4
6.6
Dimension (LxWxH)mm
3000x1050x2800
3000x1050x3400
4000x2200x4570
The size can be customized according to your site.
Weight
700kg
800kg
1000kg
Structure:  The unit consists of the ration automatic packing scale and the selecting and matching parts: conveyer and the hemming machine. It uses spiral to feed the material, and the feed gearing is suitable for a comparatively worse fluidity of powdery material. The material is discharged forcefully by the feed gearing. The main component parts are: feeder, weighing box, clamping box, the computer control, pneumatic actuator. Main Using: It is suitable for rationing package of the powdery material in the feed, food, grain, chemical industry or particulate material. (For example the grainy material in the mixture, premix material and concentrated material, starch, chemical powder material etc.) Features: * Automatic and Manual mode. * Designed to suit open mouth bags. * Multiple product types can be bagged. * Easy to clean, easy to maintain. * System can accommodate different bag sizes using bolt-on fittings. * Easy integration with a conveyor. * Can be designed as a free-standing (as shown at left) or bolt on to existing supply bin arrangement. * Up to 100 different product target weights can be stored and recalled using the digital indicator. * Product in-flight is taken into account. * Units are built to Customer's requirements, including bin sizes, bin finishes (painted or stainless steel), mounting frame, discharge arrangement, etc.
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 1
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 2
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 3
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 4
RELATED PRODUSTS
PROJECT DISPLAY
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 5
COMPANY PROFILE
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 6
M&J Machinery Engineer Co., Ltd is one of the most professional manufacturers with 20 years experiences in manufacturing all kinds of packing scales, packing systems and conveyors such as Quantitative Auto Packing Scale, Completely Automatic Packing System, ABS Packing Scale, Buckwheat Processing Line, Screw Conveyor, Bucket Elevator, etc. Located in Wuxi, about 200 kilometers away from Shanghai. Our Company has already gotten the export license and merchandised in domestic and oversea market for many years.M&J Machinery Engineer Co., Ltd is one of the most professional manufacturers with 20 years experiences in manufacturing all kinds of packing scales, packing systems and conveyors such as Quantitative Auto Packing Scale, Completely Automatic Packing System, ABS Packing Scale, Buckwheat Processing Line, Screw Conveyor, Bucket Elevator, etc. Located in Wuxi, about 200 kilometers away from Shanghai. Our Company has already gotten the export license and merchandised in domestic and oversea market for many years.
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 7
CERTIFICATIONS
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 8
WHY CHOOSE US
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 9
Permanent investment in research and development, We are specialists in bagging bulk solids in all sorts of bags: Valve bags, Open mouth bags, FFS bags and Big Bags.
We have delivered and installed more than 3,000 machines worldwide. All of our quality machinery complies with the CE conformity, MID European Certification for weights and measurements.
We have a professional team to provide you with 24-hour online service, And, our efficient after sales service is present worldwide.
COOPERATIVE CLIENT
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 10
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 11
Quantitative Range 5-50kg Electric Driven Automatic Grain Valve Bag Packing Filling Machine 12
